Prozessor
Prozessorfamilie
Intel® Core™ i5 der siebten Generation
Prozessor-Taktfrequenz
2,6 GHz
Prozessor-Serien
Intel Core i5-7300 Mobile Series
TDP-down Frequenz konfigurierbar
0,8 GHz
TDP-down konfigurierbar
7,5 W
TDP-up Frequenz konfigurierbar
2,7 GHz
Prozessorbetriebsmodi
64-Bit
TDP-up konfigurierbar
25 W
Prozessorhersteller
Intel
Prozessor Boost-Frequenz
3,5 GHz
Prozessor Cache Typ
Smart Cache
Thermal Design Power (TDP)
15 W
Prozessor Codename
Kaby Lake
Prozessor Lithografie
14 nm
PCI Express Konfigurationen
1x2+2x1,1x4,2x2,4x1
PCI-Express-Slots-Version
3.0
Maximale Anzahl der PCI-Express-Lanes
12
Speicher
Interner Speichertyp
LPDDR3-SDRAM
Speichertaktfrequenz
1866 MHz
RAM-Speicher maximal
16 GB
Bildschirm
Bildschirmdiagonale
30,5 cm (12 Zoll)
Bildschirmauflösung
2160 x 1440 Pixel
LED-Hintergrundbeleuchtung
Ja
Touch-Technologie
Multitouch
Art des Touchscreens
Kapazitiv
Audio
Anschlüsse und Schnittstellen
Anzahl serielle Anschlüsse
1
Anzahl USB 2.0 Anschlüsse
1
Anzahl Ethernet-LAN-Anschlüsse (RJ-45)
2
Anzahl USB 3.2 Gen 1 (3.1 Gen 1) Typ-A Ports
3
Anzahl VGA (D-Sub) Anschlüsse
1
Typ Ladeanschluss
DC-Anschluss
Gewicht und Abmessungen
Leistung
Netzteil Eingansgsspannung
100 - 240 V
Netzteilfrequenz
50 - 60 Hz
Betriebsbedingungen
Temperaturbereich in Betrieb
-29 - 60 °C
Technische Details
Nachhaltigkeitszertifikate
RoHS, EPEAT Silver, ENERGY STAR, RoHS
Tastatur
Tastatur - Tastenanzahl
87
Tastatur mit Hintergrundbeleuchtung
Ja
Netzwerk
Top WLAN-Standard
Wi-Fi 5 (802.11ac)
Ethernet LAN Datentransferraten
10,100,1000 Mbit/s
WLAN-Standards
802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)
Eingebauter Ethernet-Anschluss
Ja
Speichermedium
Gesamtspeicher-Kapazität
256 GB
Integrierter Kartenleser
Ja
Gesamtkapazität der SSDs
256 GB
Kompatible Speicherkarten
SD,SDXC
SSD Speicherkapazität
256 GB
Sicherheit
Slot-Typ Kabelsperre
Kensington
Trusted Platform Module (TPM)
Ja
Zertifikate
Energy Star-zertifiziert
Ja
Zertifizierung
MIL-STD-461F, MIL-STD-810G, Ingress Protection (IP65), ISO Certification, Section 508 Standards, Verizon, AT&T, Sprint
Software
Installiertes Betriebssystem
Windows 10 Pro
Betriebssystemsarchitektur
64-Bit
Kamera
Auflösung Frontkamera
1920 x 1080 Pixel
Auflösung Frontkamera (numerisch)
2 MP
Auflösung Rückkamera (numerisch)
8 MP
Lieferumfang
Batterie
Batterietechnologie
Lithium-Ion (Li-Ion)
Sonstige Funktionen
Design
Produktfarbe
Schwarz, Silber
Formfaktor
Austauschbar (Abnehmbar)
Produkttyp
Hybrid (2-in-1)
Marktpositionierung
Business
Grafik
Dediziertes Grafikadaptermodell
Nicht verfügbar
Separater Grafikadapter
Nein
Maximale dynamische Frequenz der On-Board Grafikadapter
1100 MHz
Maximaler integrierter Grafik-Adapterspeicher
32 GB
On-Board Grafikadapter Basisfrequenz
300 MHz
On-Board Grafikadapter DirectX Version
12.0
On-Board Grafikadapter Geräte-ID
0x5916
On-Board Grafikadapter OpenGL Version
4.4
On-Board Grafikadaptermodell
Intel® HD Graphics 620
On-Board-Grafikadapterfamilie
Intel® HD Graphics
Prozessor Besonderheiten
Intel® Clear Video Technology für Mobile Internet Devices (Intel® CVT for MID)
Ja
Intel® Smart Response Technologieversion
1,00
Eingebettete Optionen verfügbar
Ja
Unterstützte Befehlssätze
AVX 2.0,SSE4.1,SSE4.2
Verbesserte Intel SpeedStep Technologie
Ja
Intel® Enhanced Halt State
Ja
Intel® Quick-Sync-Video-Technik
Ja
Intel® Smart-Response-Technologie
Ja
Intel® Software Guard Extensions (Intel® SGX)
Ja
CPU Konfiguration (max)
1
Intel® Stable Image Platform Program (SIPP) Version
1,00
Intel® Flex Memory Access
Ja
Intel® Trusted-Execution-Technik
Ja
Konfliktloser-Prozessor
Ja
Intel Stable Image Platform Program (SIPP)
Ja
Intel® Hyper-Threading-Technik (Intel® HT Technology)
Ja
Intel® TSX-NI-Version
1,00
Intel® Identity Protection Technologieversion
1,00
Intel® Secure Key Technologieversion
1,00
Intel® Turbo-Boost-Technologie
2.0
Intel® Identity-Protection-Technologie (Intel® IPT)
Ja
Intel® AES New Instructions (Intel® AES-NI)
Ja
Intel® Sicherer Schlüssel
Ja
Intel® Virtualisierungstechnik für direkte I/O (VT-d)
Ja
Thermal-Überwachungstechnologien
Ja
Intel® Virtualization Technologie (VT-X)
Ja
ARK Prozessorerkennung
97472
Intel® Clear Video HD Technology für (Intel® CVT HD)
Ja
Intel® My-WiFi-Technik (Intel® MWT)
Ja
Intel® VT-x mit Extended Page Tables (EPT)
Ja
Prozessor-Paketgröße
42 x 24 mm
Intel® Clear Video Technologie
Ja
